Introducing the Hillcrest Trailers

10K DUMP TRAILER

A HEAVY DUTY WORKHORSE DESIGNED FOR THE TOUGHEST JOBS

INTRODUCING THE HILLCREST TRAILERS

GOOSENECK DUMP TRAILER

A HEAVY DUTY WORKHORSE DESIGNED FOR THE TOUGHEST JOBS

3 Year Limited

WARRANTY

12'

LENGTH

73"

WIDTH

10K

GVWR

3 Year Limited

WARRANTY

12'

LENGTH

73"

WIDTH

10K

GVWR

Introducing the 10K Standard Duty Dump trailer from Hillcrest Trailers! This top-of-the-line trailer features 2 - 6000# Premium Axles with Cambered Axles and Quick-Lubricating Hubs for a smooth ride. The forward self-adjusting electric brakes on both axles provide added safety and control. With a multi-leaf slipper spring suspension and equalizer, this trailer can handle heavy loads with ease. The 6” I-Beam tongue and adjustable coupler make hitching and towing a breeze. Plus, the 7,000# Top Wind jack and 6” I-Beam frame ensure stability and durability on the road.


For added convenience, the trailer comes equipped with stake pockets along both sides, recessed LED lighting, and a sealed modular wiring harness. The ST225/75 R-15 tires and black mod steel wheels provide reliable performance on any terrain. With a rear combo gate, J-hooks for cargo control, and 20” tall sides, this trailer is perfect for transporting equipment and materials. The fully-formed tarp shroud and lockable pump and battery box offer added security and protection.


Whether you’re hauling equipment or materials, the 10K Standard Duty Dump trailer is the perfect choice. With a GVWR of 9,995lbs and a width of 73”, this trailer comes in a 12’ size to suit your needs. Trust Hillcrest Trailers for quality, reliability, and performance in every journey.

MODEL LENGTH WIDTH WEIGHT PAYLOAD
10612SSD 12' 73" 3,150lbs 6,845lbs

 Optional Equipment


  • Spare Tire to Fit Included Tire Mount


CATEGORY SPECIFICATIONS
Axles 2 - 6000# Premium, Cambered Axles with Quick-Lubricating Hubs
Brakes Forward Self-Adjusting Electric Brakes on Both Axles
Suspension Multi-Leaf Slipper Spring w/ Equalizer
Tongue 6" I-Beam, 9lbs. per foot
Coupler 2-5/16" Adjustable Coupler
Safety Chains 1/4” Grd. 70 w/Safety Latch Hook (2 each)
Jack 7,000# Top Wind,Drop Leg, Set-Back Jack
Frame 6" I-Beam, 9lbs. per foot
Cross-Members Full Length Fabricated 10 ga Braces
Floor 10 ga
Fenders Double Broke
Ramps 6.5' Heavy Duty Ramps
Stake Pockets Stake Pockets Along Both Sides
Trailer Plug 7-Way RV
Wiring Sealed Modular Wiring Harness
Tires ST225/75 R-15 Load Range D
Bolt Pattern 6 Bolt
Tie-Downs (6) 5/8" D-Rings Inside Bed to Secure Equipment Along Sides and Rear for Cargo Control
Charger 5A 110V on Board Battery Charger
Gate Rear Combo Gate (Barn Doors & Spreader Gate)
J-Hooks Along sides for Cargo Control
Power Power Up/Gravity Down Movement
Ram 12-Ton 3- Stage Telescopic Cylinder
Sides 20" Tall
Stabilizers Optional Rear Stabilizer Stands
Steps Convenient Side-Step for Easy Access
Storage Lockable Pump and Battery Box mounted in Front of Bed
Tarp Fully-Formed Tarp Shroud with Tarp & Rear Tarp Rod Holders
Top Rail Formed Strong Rail

Introducing the 10K Standard Duty Dump trailer from Hillcrest Trailers! This top-of-the-line trailer features 2 - 6000# Premium Axles with Cambered Axles and Quick-Lubricating Hubs for a smooth ride. The forward self-adjusting electric brakes on both axles provide added safety and control. With a multi-leaf slipper spring suspension and equalizer, this trailer can handle heavy loads with ease. The 6” I-Beam tongue and adjustable coupler make hitching and towing a breeze. Plus, the 7,000# Top Wind jack and 6” I-Beam frame ensure stability and durability on the road.


For added convenience, the trailer comes equipped with stake pockets along both sides, recessed LED lighting, and a sealed modular wiring harness. The ST225/75 R-15 tires and black mod steel wheels provide reliable performance on any terrain. With a rear combo gate, J-hooks for cargo control, and 20” tall sides, this trailer is perfect for transporting equipment and materials. The fully-formed tarp shroud and lockable pump and battery box offer added security and protection.


Whether you’re hauling equipment or materials, the 10K Standard Duty Dump trailer is the perfect choice. With a GVWR of 9,995lbs and a width of 73”, this trailer comes in a 12’ size to suit your needs. Trust Hillcrest Trailers for quality, reliability, and performance in every journey.

MODEL LENGTH WIDTH WEIGHT PAYLOAD
10612SSD 12' 73" 3,150lbs 6,845lbs

 Optional Equipment


  • Spare Tire to Fit Included Tire Mount


LITERATURE

DOWNLOAD

MANUAL

DOWNLOAD

PARTS LIST

PARTS LIST
CATEGORY SPECIFICATIONS
Axles 2 - 6000# Premium, Cambered Axles with Quick-Lubricating Hubs
Brakes Forward Self-Adjusting Electric Brakes on Both Axles
Suspension Multi-Leaf Slipper Spring w/ Equalizer
Tongue 6" I-Beam, 9lbs. per foot
Coupler 2-5/16" Adjustable Coupler
Safety Chains 1/4” Grd. 70 w/Safety Latch Hook (2 each)
Jack 7,000# Top Wind,Drop Leg, Set-Back Jack
Frame 6" I-Beam, 9lbs. per foot
Cross-Members Full Length Fabricated 10 ga Braces
Floor 10 ga
Fenders Double Broke
Ramps 6.5' Heavy Duty Ramps
Stake Pockets Stake Pockets Along Both Sides
Trailer Plug 7-Way RV
Wiring Sealed Modular Wiring Harness
Tires ST225/75 R-15 Load Range D
Bolt Pattern 6 Bolt
Tie-Downs (6) 5/8" D-Rings Inside Bed to Secure Equipment Along Sides and Rear for Cargo Control
Charger 5A 110V on Board Battery Charger
Gate Rear Combo Gate (Barn Doors & Spreader Gate)
J-Hooks Along sides for Cargo Control
Power Power Up/Gravity Down Movement
Ram 12-Ton 3- Stage Telescopic Cylinder
Sides 20" Tall
Stabilizers Optional Rear Stabilizer Stands
Steps Convenient Side-Step for Easy Access
Storage Lockable Pump and Battery Box mounted in Front of Bed
Tarp Fully-Formed Tarp Shroud with Tarp & Rear Tarp Rod Holders
Top Rail Formed Strong Rail

LITERATURE

DOWNLOAD

MANUAL

DOWNLOAD

PARTS LIST

PARTS LIST
