Introducing the Hillcrest Trailers
EQUIPMENT TRAILER
A HEAVY DUTY WORKHORSE DESIGNED FOR THE TOUGHEST JOBS
INTRODUCING THE HILLCREST TRAILERS
14K EQUIPMENT TRAILER
A HEAVY DUTY WORKHORSE DESIGNED FOR THE TOUGHEST JOBS
3 Year Limited
WARRANTY
20'/22'/24'/26'
LENGTH
82"
WIDTH
14K or 16K
GVWR
3 Year Limited
WARRANTY
20'/22'/24'/26'
LENGTH
82"
WIDTH
14K or 16K
GVWR
Introducing the Hillcrest Trailers Equipment Trailer! This heavy-duty trailer is perfect for transporting all your equipment with ease.
With 2 - 7000# (14K) or 2-8000# Hybrid (16K) Premium Cambered Axles, Forward Self Adjusting Electric Brakes, and Multi-Leaf Slipper Spring Suspension, you can trust that your cargo will be secure on the road. The 6” Channel Wrap Tongue, Adjustable Coupler, and 12,000# Top Wind Jack make hitching and unhitching a breeze. The durable 6” Factory Channel Frame and 3” Factory Channel Cross-Members ensure strength and stability while the 2” Treated Pine Floor and Removable Double Broke Fenders add convenience.
The 5’ Stand-up Ramps and 2’ Dovetail make loading and unloading simple, and with Stake Pockets, Tie-Downs, and LED Lights, safety is a priority. Choose from sizes ranging from 18+2 to 24+2 to suit your needs.
Trust the reliability and quality of Hillcrest Trailers with our Equipment Trailer. Get yours today and hit the road with confidence!
14k Trailer Specs
| MODEL | AXLES | LENGTH | WIDTH | WEIGHT | PAYLOAD |
|---|---|---|---|---|---|
| 14182SE | 2-7000# | 18' + 2' | 82" | 3,480lbs. | 10,520lbs |
| 14202SE | 2-7000# | 20' + 2 | 82" | 3,590lbs. | 10,410lbs. |
| 14222SE | 2-7000# | 22' + 2' | 82" | 3,700lbs. | 10,300lbs. |
| 14242SE | 2-7000# | 24' + 2' | 82" | 3,858lbs. | 10,142lbs. |
16k Trailer Specs
| MODEL | AXLES | LENGTH | WIDTH | WEIGHT | PAYLOAD |
|---|---|---|---|---|---|
| 16182SE | 2-8000# Hybrid | 18' + 2' | 82" | 3,730lbs. | 12,240lbs. |
| 16202SE | 2-8000# Hybrid | 20' + 2 | 82" | 3,840lbs. | 12,168lbs |
| 16222SE | 2-8000# Hybrid | 22' + 2' | 82" | 3,950lbs. | 12,050lbs |
| 16242SE | 2-8000# Hybrid | 24' + 2' | 82" | 4,078lbs. | 11,920lbs |
Optional Equipment
- Tool Box
- Spare Tire Mount
- Spare Tire
| CATEGORY | SPECIFICATIONS |
|---|---|
| Axles (14K) | 2 - 7000# Premium, Cambered Axles with Quick-Lubricating Hubs |
| Axles (16K) | 2 - 8000# Premium Hybrid, Cambered Axles with Quick-Lubricating Hubs |
| Brakes | Forward Self Adjusting Electric Brake on Both Axles |
| Suspension | Multi-Leaf Slipper Spring w/Equalizer |
| Tongue | 6" Channel Wrap Tongue |
| Coupler (14K) | 2-5/16" Adjustable Coupler |
| Coupler (16K) | 2-5/16" Adjustable Demco Coupler |
| Safety Chains | 3/8" Grade 70 w/Safety Latch Hook (2 each) |
| Jack | 12,000# Top Wind,Drop Leg, Set-Back Jack |
| Frame | 6" Factory Channel |
| Cross-Members | 3" Factory Channel |
| Front Stop Rail | 3/16" Fabricated Front Stop Rail |
| Floor | 2" Treated Pine |
| Fenders | Removable Double Broke Fenders |
| Ramps | 5' Stand-up Ramps |
| Dovetail | 2' Dovetail |
| Stake Pockets | Stake Pockets Along Both Sides (Quantity Varies by Length) |
| Tie-Downs | 4- 5/8" Welded D-rings |
| Trailer Plug | 7-Way RV |
| Lights | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| Wiring | Sealed Modular Wiring Harness |
| Tires | ST235/80 R-16 Load Range E |
| Bolt Pattern | 8 Bolt |
| Spare Tire | Optional |
| Paint Type | Sherwin Williams Super Durable Powder |
| Paint Color | Black Gray |
| Sizes (ft) | 18+2, 20+2, 22+2, 24+2 |
